Window fixing system, mounting adaptors

€6.00
TTC
Estimated delivery between 20 October and 23 October
Quantity

One mounting adaptor for MILLA handles



Secure payment



Tracked international delivery



Returns and exchanges within 90 days



French after-sales service

Window handle adaptor

This window adaptor provides a mechanical connection between the handle components, as shown in the technical drawing.

Dimensions shown in the diagram:

  • Mounting plate height: 62 mm
  • Mounting plate width: 29 mm
  • Fixing hole centres: 43 mm
  • Fixing hole diameter: 5.4 mm
  • Square spindle sizes shown: 7 mm and 8 mm
  • Length of 8 mm square section: 32 mm
  • Length of 7 mm square section: 40 mm

Before ordering, we recommend checking the dimensions and window fixing system to ensure this adaptor fits the existing installation.

Data sheet

Material
Steel
Unit of sale
Per piece
